01 First-Time Setup

Your Pre-Flight Checklist

Just got your Rowsfire panel? Follow this 5-step checklist. Click each box as you go — total time roughly 10 minutes.

▸ ROWSFIRE · PRE-FLIGHT CHECKLIST
0 / 3 COMPLETE
CHECK 01

Unbox & connect to USB

Plug your panel into a rear USB 3.0 port (blue port). Avoid front ports and unpowered hubs — they cause backlight flicker.

~1 min
CHECK 02

Choose your control software

Rowsfire App — recommended, plug-and-play, no configuration needed. Or use MobiFlight with our pre-built config files for advanced programmable customization.

~30 sec
CHECK 03

MobiFlight users: Download config, import & fly

⚠ Only required if using MobiFlight. If you're using Rowsfire App, you're done — skip this step.

1. Download: Find your panel + aircraft combo below in the Device Resources section. One-click download for Fenix A320, FBW A32NX, ToLiss A320, and PMDG 737.

2. Import: Open MobiFlight → File → Import → select the .mcc file. Status should turn green. If gray, re-plug USB.

3. Launch: Start MSFS / X-Plane → load your aircraft → click RUN in MobiFlight. A green checkmark in the bottom-right means full handshake. You're cleared for takeoff. ✈

~8 min
02 Core Resources

Guides, videos & tools

Six essential resources to set up, troubleshoot, and master your Rowsfire panel.

SOFTWARE

Rowsfire App

Plug-and-play control software. The fastest way to get your panel running — recommended for 95% of users.

⚡ 60-second setup Download →
GUIDE

MobiFlight + FSUIPC7 Setup

Full step-by-step guide for the classic MobiFlight workflow — ideal for advanced multi-panel cockpits.

📖 12 min read Read →
CONFIG FILES

MobiFlight Config Library

Pre-built .mcc files for every panel × aircraft combo. Sorted by model, version, and aircraft type.

📦 50+ configs Browse →
REPOSITORY

GitHub: RF-Connect

Open-source firmware, latest releases, and changelog. For developers and power users.

🔧 Open source View →
VIDEO

Setup Walkthrough

Watch a complete unbox-to-flight setup from scratch. Visual learners, this is for you.

▶ 8 min watch Play →
ADVANCED

Multi-Panel Setup Guide

Connecting 2+ panels at once? Avoid COM port conflicts and signal collisions with this guide.

📖 6 min read Read →
03 Device Resources

Find resources for your panel

Click your panel to access its config files, firmware, and aircraft-specific guides.

A101SUPPORTED

A320 Mini Light Overhead Panel

Product Config
A103SUPPORTED

XECAM + Landing Gear Indicator Panel

Product Config
A105SUPPORTED

All-in-One RMP + ATC Panel

Product Config
A106SUPPORTED

A320 Pro Light Overhead Panel V2.0

Product Config
A107SUPPORTED

A320pro / A320 MAX Light Overhead

Product Config
A107 ProSUPPORTED

A320 Pro Aluminum-Frame Overhead

Product Config
A108SUPPORTED

PFD-ND-ECAM-EWD 4-in-1 Display

Product Config
A109SUPPORTED

ATT-ADIRS-EIS Integrated Panel

Product Config
A110PSUPPORTED

A320 Flight Simulator Pedestal Stand

Product
A111SUPPORTED

RMP-ACP Radio & Audio Panel

Product Config
A112SUPPORTED

CKPT-LT + WXR-Radar Integrated Panel

Product Config
A113SUPPORTED

CKPT-LT + DFOR + ATC Panel

Product Config
A115NEW

1:1 Scale FPD-ND Panel

Product
A116NEW

1:1 Scale ECAM-EDCU Panel

Product
A117NEW

1:1 Scale Glareshield Panel

Product
B101SUPPORTED

B737 EFIS-ECP Panel

Product Config
B107SUPPORTED

B737 Overhead Panel · PMDG / Zibo / iFly

Product Config
A108CROSS-COMPATIBLE

PFD-ND-ECAM-EWD (works with B-Series too)

Product Config
D101SUPPORTED

F/A-18 Universal Carrier Landing Switch

Product
D102SUPPORTED

A-10C Warthog UFCP Control Panel

Product
D103SUPPORTED

G1000 NXi Panel Set

Product
D104SUPPORTED

G1000 NXi MFD Panel

Product
D105SUPPORTED

G1000 NXi Panel Set

Product
04 Self-Diagnosis

Something not working? Start here.

Pick the issue closest to what you're experiencing. We'll walk you through the fix.

What's the issue?

▸ DIAGNOSIS · POWER ISSUE

  1. Move USB cable to a rear USB 3.0 port (blue) on your motherboard. Front ports often deliver insufficient power.
  2. If using a USB hub, switch to a powered hub with its own AC adapter, or remove the hub entirely.
  3. Try a different USB cable (some thin cables can't carry enough current for the backlight).
Still flickering? Contact support →

▸ DIAGNOSIS · CONNECTION FAILED

  1. Disable firewall and antivirus during installation. They sometimes block MobiFlight's serial communication.
  2. In MobiFlight, go to Settings → MobiFlight Modules. Check the COM port — it should be green. If gray, re-plug the USB.
  3. Confirm you're running MobiFlight v10.5.0 or later. Older versions don't recognize newer Rowsfire firmware.
  4. If still not detected, try the Rowsfire App instead — it bypasses MobiFlight entirely.
Need a deeper diagnosis? Run the troubleshooting guide →

▸ DIAGNOSIS · CONFIG MISMATCH

  1. Make sure you imported the correct .mcc file for your aircraft. Fenix A320 uses fenixA320.mcc; FBW A32NX uses a different file.
  2. FSUIPC7 must be running. Verify the green checkmark appears in MobiFlight's bottom-right.
  3. In MSFS, go in-game and click RUN in MobiFlight. Switches start working only after this handshake.
Wrong config file? Browse the full library →

▸ DIAGNOSIS · FALSE POSITIVE

  1. This is a known false positive on small-publisher Windows software. The Rowsfire App is signed and safe.
  2. Click "More info" → "Run anyway" on the Windows SmartScreen popup.
  3. If using a third-party antivirus, add the install folder to the exception list before re-running setup.
  4. Versions 1.7.1 and later include a verified signing certificate that resolves most warnings.
Source code is publicly auditable on GitHub →

▸ DIAGNOSIS · OUTDATED FIRMWARE

  1. Rotation reversed or buttons mapped wrong? Re-download the latest firmware for your panel — switch-reverse issues for A112 V1.1, A113 V1.1, and A105 V3.2 were fixed in app v2.3.
  2. In the Rowsfire App, check for updates on launch. For MobiFlight users, re-import the latest .mcc from the config library.
  3. If you're using a known-buggy combo (e.g. B107 + PMDG with reversed DIM switch), check the v2.3 changelog for the latest fixes — re-flash firmware after updating.
Custom remap needed? Ask in the community →

▸ DIAGNOSIS · DATA SYNC ISSUE

  1. If both MSFS 2020 and 2024 are installed, make sure both bridge files are installed (auto-fixed in app v2.0+).
  2. For lag on rotary encoders, update to the latest app version — encoder latency was improved in v2.1+.
  3. Verify FSUIPC7 v7.3.0+ is running — older versions cause display refresh issues.
  4. Running 3+ panels (A111 + A112 + A113) on the same USB hub? Try plugging one into the motherboard's built-in USB and the rest into the hub — overload can cause one device to drop off.
Display still wrong? Send us your panel model + sim version →
05 Get Help

Talk to a real human.

Local engineers, active community, and human support during business hours. Pick the channel that fits.

Email Support

Send your panel model, software (App or MobiFlight) and a screenshot — we'll reply with a fix.

service@rowsfire.com · ~24h reply

Facebook Group

3,000+ home cockpit builders. Post a photo, get help in hours from fellow simmers.

Join 3,000+ Members

Discord Server

Real-time chat with power users, beta testers, and the Rowsfire dev team.

discord.gg/NxDFP3SZHx

WhatsApp Support

1-on-1 video guidance in your local language. Direct line to a tech engineer.

+86 157 2884 5227 · business hours
