Rowsfire A320 Overhead Panel User Guide

September 02, 2025 Jerry Az

1. Install MobiFlightConnector-10.5.0

After installation:

Do NOT install the beta version of the software.
During installation, disable your firewall and antivirus software.
Click "Allow" for all software permission requests; otherwise, the software may not install completely.
If needed, you can contact us directly to obtain the pre-extracted software package.

2. Install FSUIPC7

3. Load the Configuration File in MobiFlightConnector

Open MobiFlightConnector and load the configuration file:

For the FENIX A320 aircraft model: Load fenixA320-MINI-DB.mcc.
For the FBW aircraft model: Load FBW-A320-MINI-DB.mcc.
Note: Download the configuration file corresponding to your aircraft model.

4. Load the Hardware Device

Load the hardware device (this only needs to be done once). The software will automatically recognize the device when opened again.

5. Launch Microsoft Flight Simulator 2020 & Connect Hardware

After launching Microsoft Flight Simulator 2020, FSUIPC7 will run automatically.
Select the FENIX A320 aircraft model, enter the game, and click "RNU" to load the hardware. You can then use the light peripheral in the game.
Note: After properly installing and launching all software, hardware, and the game, a green checkmark (√) will appear in the bottom right corner. If a yellow exclamation mark appears, check whether the software is installed correctly.

6. About MobiFlightConnector

MobiFlightConnector is button-binding software between peripherals and games, featuring powerful functions for defining buttons of gaming peripherals. You can:

Check the software’s help page.
Watch tutorial videos on the official website.
Customize the hardware to support more different aircraft models for gameplay.
Feel free to contact us if you need assistance. Enjoy your flight!

Special Notes: Common Issues & Solutions

1. Issue: No response when the device is plugged into the computer, or the device is not recognized properly

Solution: Connect the device to the USB port on the motherboard at the back of the host to ensure sufficient power supply for the device.

2. Issue: After all software is installed, the device fails to interact with the game (a yellow exclamation mark appears in MobiFlightConnector)

Solution:
Copy the \MSFS2020-module\mobiflight-event-module folder from the MobiFlightConnector installation directory to your Community folder (\Community).

3. Issue: Missing preset configuration files / Custom button mapping

If there is no preset file, contact us to obtain it.
If you want to create custom mappings, refer to this link: https://docs.mobiflight.com/getting-started/

That’s all for the A320 overhead panel configuration guide—we hope it helps you get your setup running smoothly! If you hit any snags, leave a comment below or reach out to our support team at service@mechdiy.com.

And if you’re ready to grab a Rowsfire product, head to our official channels to shop—happy flying!
